Model:SC4212D
|
|
Features
|
Superiority
|
Support monitor via computer and most of intelligent cell phone on the market(such as Android ,iphone cell phone
|
|
mobile software
|
Provide special software for the iPhone or android mobile phone
|
|
DDNS（free）
|
Built in free DDNS system
|
|
CMS software
|
Sysvideo multi-window management software ,remote recording
|
|
System security
|
Supports three-level account, password, user multi-level authority management
|
|
Local memory
|
Support 32G TF card local memory, support alarm recording and picture memory, Support Sysvideo NVR
|
|
CPU
|
Operation system
|
Embedded Linux OS
|
|
Microcomputer processor
|
32Bit RSIC Embedded Processor
|
|
Network
|
Network interface
|
RJ-45 10/100Mb self-adaptable Ethernet slot
|
|
Protocol
|
Support HTTP，UDP，SMTP，FTP，DHCP，DNS，DDNS，NTP，UPNP
|
|
Wireless
|
Wifi802.11 b/g/n
|
|
IP mode
|
Dynamic IP address, static IP address
|
|
|
Online visitor
|
Main stream support 5 visitors at the same time
|
|
Time stream support 6 visitors at the same time
|
|
Video
|
Compression format
|
H.264
|
|
Image sensor
|
CMOS 1000,000 pixel
|
|
Lens
|
Standard: 3.6mm
|
|
Frame rate
|
1-25fps
|
|
Resolution
|
720P(1280*720) (640*360) (320*180)
|
|
Image adjustment
|
Brightness, contrast, color saturation, chroma
|
|
WB, BLC
|
Auto
|
|
LUX
|
0.3LUX/F1.2
|
|
SNR
|
>48dB
|
|
Audio
|
Compression format
|
G.711/G.726
|
|
Input
|
Two way audio, one channel linear input(powered MIC) and output
|
|
Output
|
Audio output
|
|
PTZ
|
Motor
|
Built-in motor control
|
|
Rotation angle
|
Horizontal:355° vertical: 80°
|
|
PTZ Protocol
|
No
|
|
Nightvision
|
Filter switch
|
Can auto-switch automatically, without color cast
|
|
Nightvision
|
13Φ3 LED lights IR distance: 10m
|
|
Alarm
|
Input/output
|
1 channel RS485
|
|
Alarm detection
|
Motion detection
|
|
|
Detection area
|
Support 4 detection area
|
|
Alarm notification
|
Email notification, picture, save the recording and picture to tf card
|
|
Others
|
Shape material
|
Plastic
|
|
Environment
|
Indoors
|
|
Power supply
|
DC5V 2A
|
|
Operating temperature
|
-10~50°C
|
|
Operating humidity
|
10%~90%RH
|
|
Dimension
|
Item size :120 x 120 x 130mm (L*W*H)
|
|
Package size：170 x170 x 170mm (L*W*H)
|
|
Weight
|
Item weight：340g （Note:for real products ）
|
|
Package weight：700g
|
|
Accessories
|
Power adapter, CD, manual, warranty card, screws ,bracket ,antenna
|
|
System
|
System requirement
|
Microsoft WinXP, Vista ，win7， IE6.0、7.0、8.0、9.0, NET4.5，firefox，chrom
|
|
Certification
|
Certificate
|
ISO FCC CE RoHS
|
