Model
|
IR
|
POE
|
LENS
|
|
SC6321-ZF
|
Yes
|
Yes
|
2.8-12m motorized zoom & auto focus lens
|
|
Image Sensor
|
1/2.8” 2.0 megapixels Progressive Scan Sony CMOS
|
|
CPU
|
HI3516C with 500MHZ
|
|
Effective Pixels
|
1920x1080
|
|
Scanning System
|
Progressive
|
|
Electronics Shutter Speed
|
Auto (1/25,1/30 ~ 1/10000s)
|
|
Min. Illumination
|
0.001Lux @F1.2(ICR, AGC ON)
|
|
S/N Ratio
|
>50dB
|
|
Camera Features
|
|
Day/Night
|
Color / B/W
|
|
Backlight Compensation
|
BLC / HLC / WDR (digital)
|
|
White Balance
|
Auto
|
|
Gain Control
|
Auto
|
|
Noise Reduction
|
3D
|
|
Privacy Masking
|
Up to 4 Areas
|
|
Lens
|
|
Focal Length
|
2.8-12m
|
|
Max Aperture
|
F1.4
|
|
Focus Control
|
Auto
|
|
Iris
|
Auto
|
|
Angle of View
|
92°~ 27°
|
|
Lens Type
|
Motorized zoom
|
|
Mount Type
|
Board-in Type
|
|
Video
|
|
Compression
|
H.264 / MJPEG
|
|
Resolution
|
1920x1080, 1280x720 ; 640x320, 320x160, 160x112
|
|
Frame Rate
|
Preferred Stream
|
1920x1080(1~25/30fps), 1280x720(1~25/30fps)
|
|
Alternate Stream
|
640x320, 320x160, 160x112 (1~25/30fps)
|
|
Bit Rate
|
32KB ~16Mbps, support VBR, CBR
|
|
Audio(“-AV” only)
|
|
Compression
|
G.711a / G.711U, G.726
|
|
Interface
|
1 channel Input, 1 channel Output
|
|
Network
|
|
Ethernet
|
RJ-45 (10/100Base-T)
|
|
Protocol
|
IPv4/IPv6, HTTP, TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP,
|
|
ONVIF
|
ONVIF Ver. 2.0
|
|
Max. User Access
|
10 users
|
|
Smart Phone
|
iPhone, iPad, Android, Symbian
|
|
Auxiliary Interface
|
|
Memory Slot
|
Micro SD, Max 32GB
|
|
Alarm(“-AV” only)
|
1channel Input, 1 channel Output
|
|
General
|
|
Power Supply
|
DC12V, POE (802.3af)
|
|
Power Consumption
|
≤5W
|
|
Working Environment
|
-20 ℃ ~ 60℃
|
|
Dimensions
|
Φ147.7mm ×99mm
|
|
Weight
|
0.5KG
|
