You are here:Home > Products > Network Video Recorder > Enterprise RAID NVR
SNK16128RD Series:  16 HDD RAID0/1/5/6/10 32/64/128ch 1080P Enterprise Embedded Linux NVR
Description:
it support 32/64/128 channel 1080P input and 3MP camera, 16 x 1080p@30fps video decoding capability, RAID0/1/5/6/10. Its own HDMI, VGA output (can display different content at same time). It is suitable for professional enterprise IP HD surveillance system.

High-performance, High-capacity

Up to 32/64/128 channel 1080P input and 3MP supported
16 x 1080p@30fps video decoding capability
4K video output supported
Up to 160/320/ 640Mbps incoming bandwidth
512Mbps output bandwidth
64 user access simultaneously
Max. 16 HDDs hot swappable, up to 64TB storage
IP SAN and e-SATA storage supported

High reliability

Embedded Linux
RAID 0/1/5/6/10
Support Automatic Network Replenishment (ANR)
Support Packet Loss Recovery (PLR)
Redundant Power Supply (optional)

Easy to install

Auto network organizing
Built-in DHCP server

Abundant functions and features

2 HDMI + 1 VGA triple screen display video output simultaneously output different content
Support E-Map, TV-Wall
Bi-directional audio, Broadcasting
NAT, Socks5
Alarm management
Free CMS (NVR Station), support 128 NVR simultaneously management
CMS support 6 screens simultaneously (4 x Live viewing, 1 x E-Map, 1 x TV-Wall)



Software Interfaces:

 NVRStation 36ch Splitter

NVR_Station_36ch_splitter



NVRStation 64ch splitter

NVR_Station_64ch_splitter

NVRStation Playback

NVRStation Playback

NVR GUI 9ch Monitor

NVR GUI 9ch Monitor

NVR GUI Device Setting

NVR GUI Device Setting

NVR GUI HDD Management

NVR GUI HDD Management



NVR GUI Playback

NVR GUI Playback

NVR GUI Playback Smart Search

NVR GUI Playback Smart Search



SNK1632RD

SNK1664RD

SNK16128RD

Video/Audio Input

IP Camera Input

32 channel

64 channel

128 channel

Resolution

QXGA, 1080p, UXGA, 960p, 720p, XGA, SVGA, D1, CIF, QCIF

Compression Format

H.264

Protocols

Onvif, RTSP, SDK

Incoming Bandwidth

160Mbps

320Mbps

640Mbps

Live Viewing

Local Display

2 x HDMI, 1 x VGA, simultaneously output different content

Multi-Screen Display Local monitor
(Main / Secondary):

1/1/1, 4/1/1, 9/1/1, 15/1/1, 16/1/1, 24/1/1, 25/1/1, 35/1/1, 1+4/1/1, 1+8/1/1, 1+9/1/1, 1+15/1/1, 4/4/4, 9/9/9, 16/16/16

1/1/1, 4/1/1, 9/1/1, 15/1/1, 16/1/1, 24/1/1, 25/1/1, 35/1/1, 36/1/1, 48/1/1, 49/1/1, 63/1/1, 64/1/1, 1+4/1/1, 1+8/1/1, 1+9/1/1, 1+15/1/1, 4/4/4, 9/9/9, 16/16/16, 4/16/16, 16/24/24

1/1/1, 4/1/1, 9/1/1, 15/1/1, 16/1/1, 24/1/1, 25/1/1, 35/1/1, 36/1/1, 48/1/1, 49/1/1, 63/1/1, 64/1/1, 1+4/1/1, 1+8/1/1, 1+9/1/1, 1+15/1/1, 4/4/4, 9/9/9, 16/16/16, 4/16/16, 16/24/24, 35/48/48

Multi-Screen Display
Client

up to 4 screens simultaneously:
1, 3, 4, 9, 12, 16, 20, 25, 30, 36, 42, 49, 56, 63, 64
1+5, 1+7, 1+8, 1+9, 1+11, 1+15, 1+16, 1+33, 1+47, 1+48

E-Map

Live Viewing in E-Map (NVR Station)

Function

E-PTZ / Scheme / Polling / TV-Wall (optional with decoder)

Recording

Resolution

QXGA, 1080p, UXGA, 960p, 720p, XGA, SVGA, D1, CIF, QCIF

Mode

Manual / Continuous / Schedule / Event (Pre / Post)

Event Trigger

Alarm input / Video lost / Motion Detection

Tag

Supported

Reliability

Automatic Network Replenishment (ANR)

Search & Playback

Search Mode

Date & Time (Calendar) / Event

Resolution

QXGA, 1080p, UXGA, 960p, 720p, XGA, SVGA, D1, CIF, QCIF

Playback

Local monitor: 16 x 1080p@30fps

Client: 8 x 1080p@30fps

Synchronize Playback

Local monitor: 16 x 1080p@30fps

Client: 4 x 1080p@30fps

Function

Slow forward / Fast forward / Loop / Single Frame / E-PTZ

Storage

Max. Internal HDDs

16 x 3.5'' HDD

Max. 64TB (up to 4TB/each)

RAID

RAID 0/1/5/6/10

External

IP SAN (iSCSI), up to 10 x IP SAN, Max. 100T

Function

Disk group / Quota

Audio

Compression

G.711a / G.711u / ADPCM / G.722 / G.722.1c / AAC-LC

Bit rate

32kbps ~ 64kbps

Audio Function

Bi-directional audio / Dumb / Mute / Broadcasting

Alarm

Alarm Triggers

Alarm input / Video lost / Motion Detection / System alarm

Alarm Events

Snapshot / Recording / PTZ preset / Alarm out / Buzzer / Email / Link to Client / Alarm caption

System

Operation System

Embedded Linux

User Management

Admin / User

Log Management

User login / User operation / Alarm / Backup / Update

Application Programming

NVR Station SDK

Network

Network Protocol

TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, SNTP, VSIP

Viewer Software

CMS (NVR Station) / Web / iOS app / Android app

Max. User Access

64 Users

Output Bandwidth

256Mbps

Function

NAT / Socks5 / Multiple network access / Packet loss recovery / Auto network organizing

Network Test

Supported

Interfaces

Ethernet

3 x Gigabit network port, RJ45 interface

Video Out

2 x HMDI (1 HDMI up to 4K x 2k, 1 HDMI up to1920 x 1080@60Hz)

1 x VGA (up to 1920 x 1080@60Hz)

Audio In / Out

1 x RCA Line in / 1 x RCA Line out

Alarm In / Out

2 x Inputs / 2 x Outputs

Control

2 x RS485

USB

2 x USB 2.0, 2 x USB 3.0

Environmental

Operating Temperature

-10°C ~ 55°C / 14°F ~ 131°F

Operating Humidity

10% ~ 85%

Electrical

Power

100 ~ 240V AC, 50 ~ 60Hz

Power Consumption

Max. 150W (HDD not included)

Mechanical

Weight

20Kg / 44lb (HDD not included)

Dimensions

483 x 500 x 156mm / 19.02'' x 19.69'' x 6.14'
