Model
|
SNK0864B
|
|
Video/Audio Input
|
|
IP Camera Input
|
64 channel
|
|
Resolution
|
4K, 4MP, 1080p, UXGA, 960p, 720p, XGA, SVGA, D1, CIF, QCIF
|
|
Compression Format
|
H.265/H.264
|
|
Protocols
|
Onvif, RTSP, KEDACOM
|
|
Incoming Bandwidth
|
320Mbps
|
|
Live Viewing
|
|
Local Display
|
1 x HDMI, 1 x VGA, simultaneously output different content
|
|
Multi Screen Display Local monitor
(Main / Secondary):
|
1/1, 4/1, 9/1, 15/1, 16/1, 24/1, 25/1, 35/1, 36/1, 64/1, 1+4/1, 1+8/1, 1+9/1, 1+15/1, 4/9, 9/4, 9/9, 16/16
|
|
Multi Screen Display
Client
|
up to 4 screens simultaneously:
1, 3, 4, 9, 12, 16, 20, 25, 30, 36, 42, 49, 56, 63, 64
1+5, 1+7, 1+8, 1+9, 1+11, 1+15, 1+16, 1+33, 1+47, 1+48
|
|
E-Map
|
Live Viewing in E-Map (NVR Station)
|
|
Function
|
E-PTZ / Scheme / Polling / TV-Wall (optional with decoder)
|
|
Recording
|
|
Resolution
|
8MP(4K), 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 960p, 720p, XGA, SVGA, D1, CIF, QCIF
|
|
Mode
|
Manual / Continuous / Schedule / Event (Pre / Post)
|
|
Event Trigger
|
Alarm input / Video lost / Motion Detection
|
|
Tag
|
Supported
|
|
Reliability
|
Automatic Network Replenishment (ANR)
|
|
Search & Playback
|
|
Search Mode
|
Date & Time (Calendar) / Event
|
|
Resolution
|
8MP(4K), 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 960p, 720p, XGA, SVGA, D1, CIF, QCIF
|
|
Playback
(Local Monitor)
|
1 x 4K@30fps / 4 x 4MP@30fps / 16 x 1080p@30fps
|
|
Playback
(Client)
|
16 x 4K@30fps
|
|
Synchronize Playback (Local Monitor)
|
4 x 4MP@30fps / 16 x 1080p@30fps
|
|
Synchronize Playback
(Client)
|
4 x 4K@30fps
|
|
Function
|
Slow forward / Fast forward / Loop / Single Frame / E-PTZ
|
|
Storage
|
|
Max. Internal HDDs
|
8 x 3.5’’ HDD
|
|
Max. 48TB (up to 6TB/each)
|
|
External
|
IP SAN (iSCSI), up to 10 x IP SAN, Max. 100T, Max. write speed 128Mbps
|
|
e-SATA
|
|
Function
|
Disk group / Quota / Disk dormancy
|
|
Audio
|
|
Compression
|
G.711a / G.711u / ADPCM / G.722 / G.722.1c / AAC-LC
|
|
Bit rate
|
32kbps ~ 64kbps
|
|
Audio Function
|
Bi-directional audio / Dumb / Mute / Broadcasting
|
|
Alarm
|
|
Alarm Triggers
|
Alarm input / Video lost / Motion Detection / System alarm
|
|
Alarm Events
|
Snapshot / Recording / PTZ preset / Alarm out / Buzzer / Email / Link to Client / Alarm caption
|
|
System
|
|
Operation System
|
Embedded Linux
|
|
User Management
|
Admin / User
|
|
Log Management
|
User login / User operation / Alarm / Backup / Update
|
|
Aplication Programming
|
NVR Station SDK
|
|
Network
|
|
Network Protocol
|
TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, SNTP, VSIP, UPNP, IPv4, IPv6 (optional)
|
|
Viewer Software
|
CMS (NVR Station) / Web / iOS app / Android app
|
|
Max. User Access
|
64 Users
|
|
Output Bandwidth
|
256Mbps
|
|
Function
|
NAT / Socks5 / Multiple network access / Packet loss recovery / Auto network organizing
|
|
Network Test
|
Supported
|
|
Interfaces
|
|
Ethernet
|
2 x Gigabite network port, RJ45 interface
|
|
Video Out
|
1 x HMDI (up to 1920 x 1080@60Hz)
|
|
1 x VGA (up to 1920 x 1080@60Hz)
|
|
Audio In / Out
|
1 x RCA Line in / 1 x RCA Line out
|
|
Alarm In / Out
|
2 x Inputs / 2 x Outputs
|
|
Control
|
2 x RS485
|
|
USB
|
4 x USB 2.0
|
|
e-SATA
|
1 x e-SATA
|
|
Environmental
|
|
Operating Temperature
|
-10°C ~ 55°C / 14°F ~ 131°F
|
|
Operating Humidity
|
10% ~ 90%
|
|
Electrical
|
|
Power
|
100 ~ 240V AC, 50 ~ 60Hz
|
|
Power Consumption
|
Max. 30W (HDD not included)
|
|
Mechanical
|
|
Weight
|
7.6Kg / 16.72lb (HDD not included)
|
|
Dimensions
|
443 x 461 x 88mm / 17.44’’ x 18.15’’ x 3.46’’
|
